Sheep / Goat Dehairing Machine - 100/Hour


A$ 41,360.00
A$ 35,145.00
Inc. GST
A$ 37,600.00
A$ 31,950.00
Ex. GST
You save A$ 6,215.00
(No reviews yet) Write a Review
SKU:
CAT 157 100G
Availability:
Production Estimated 15 to 18 Weeks from Order
Shipping:
Calculated at Checkout

Options

A$ 41,360.00
A$ 35,145.00
Inc. GST
A$ 37,600.00
A$ 31,950.00
Ex. GST
You save A$ 6,215.00

Production Estimated 15 to 18 Weeks from Order

Description

Sheep and Goat Dehairing Machine

 Capacity 100/Hour



The Model 100G Dehairing Machine is a powerful, semi-automated solution for medium-sized abattoirs aiming to streamline sheep and goat processing. Constructed with a reinforced galvanized mild steel frame and stainless steel cover plates, it is built for durability and hygiene in demanding environments. With the ability to process up to 100 animals per hour and featuring an effective dehairing length of 1800mm, this machine significantly boosts productivity.

A standout feature is its integrated pneumatic/hydraulic cradle system, designed for seamless loading. This cradle lowers into the scalding tank to retrieve scalded animals and transfers them directly into the dehairing chamber. Both loading and discharge functions are controlled manually via intuitive levers located at the front of the machine. The discharge shaft is hydraulically lifted to automatically eject the animal once cleaning is complete. Optional PLC controls are available for enhanced automation and precision.



Features:

Up to 100 sheep or goats per hour

4 rotating shafts with durable rubber fingers for efficient dehairing

Hydraulic discharge shaft for automatic ejection of animals

Pneumatic/hydraulic loading cradle integrates with scalding tank

Galvanized mild steel frame with stainless steel covers for longevity

Dehairing efficiency exceeds 92% in 30–40 seconds per animal (singeing fine hair/scraping in armpits and polishing required for 100%)

Optional PLC timer control for automation and precision



Technical Specifications:

Effective Dehairing Length: 1800 mm

Dimensions: 2653 mm (L) × 1250 mm (W) × 1698 mm (H)

Estimated Weight: 950kg

Power: 7.5kW

Power Supply: 400V
